Armored
FO jumper/pigtail/patchcord can be deployed
directly in CO and different harsh environment,
without additional tube for protection, save
space, reduce construction cost, and make the
maintenance more conveniently. Furthermore, the
stainless steel tube prevents optic fiber from
damage, which improves security and stability of
the system.
Application:CO,
FTTH,
LAN,Test
equipment, Military industry, Measuring
Equipments, FO
cable, FO
communication system, CATV,
Optical
active component and equipment
¡ñ
Specifications
|
Parameters |
Units |
PC |
APC |
UPC |
|
Insertion
Loss |
SM |
dB |
¡Ü0.2 |
¡Ü0.2 |
¡Ü0.2 |
|
Return
Loss |
SM |
dB |
¡Ý45 |
¡Ý55 |
¡Ý65 |
|
Repeatability |
dB |
¡Ü0.1 |
|
Operating
Temperature |
¡æ |
-40~+85 |
¡¡
¡ö
Features
¡òSpecifity,
Stability and Reliable, Low Insertion Loss, High
Return Loss
¡òSingle
Mode and Multi-mode(50/125¦Ìm, 62.5/125¦Ìm) Cable
Jumpers/Pigtails are Available
¡òSingle
and Duplex are Available
¡òCable
Diameter:¦Õ3.0mm,¦Õ3.3mm
¡òWith
a Micro diameter stainless steel tube for
protection
¡òResist
destroy by improper twist
¡ò
High
resistance of tensile, pressure, rodent bite
¡ò
More
convenient to deploy and ensure safety
¡ò
Without
damage by construction
¡ò
No
need to worry about destroy in the future
¡ò
Reduce
the maintenance cost afterwards
¡¡
¡ô
Order
Information Click
Here |
Armored FO Jumper/Pigtail
